X4^
= Record resolution
1=848x480p
2=1280x720p
3=1920x1080p
X4&
= Record frame rate
1=30
2=25
3=24
4=15
5=12.5
6=12
7=10
8=5
X4*
= Output refresh rate
1=60 Hz
2=50 Hz
X4(
= Aspect Ratio
01=Fill (the input automatically fills the
entire output raster; default)
02=Follow (the input is displayed in its
native aspect ratio)
03=Fit (the input is zoomed in to fill the
entire output raster while maintaining
its aspect ratio)
X5)
= Record resolution (full):
Custom
1920x1080
1280x1024
1280x720
1024x768
848x480
X5!
= Executive mode:
0=off
1=complete lockout (no front panel
control)
2=menu lockout (menu only)
3=allow recording controls only
X6&
= EDID User location (1, 2, and 3)
X6*
= EDID resolution (see Table 1 on
page178)
X6(
= Port timeout in tens of seconds (zero
padded. Default: 00030 = 300 seconds)
X10)
= Default name: combination of model name
and last three pairs of MAC address (for
example SMP-351-07-8C-EC)
X50)
= Stream selection
1 = Archive
2 = Confidence
X50!
= Input number 1 to 5
1 or 2 digit command,
2 digit response
X50@
= Output channel
1 = A (input 1 and 2)
2 = B (input 3, 4, and 5)
X50$
= Input video format
1 = YUVp / HDTV (default)
2 = YUVi
3 = Composite
4 = 3G-SDI
5 = HD-SDI
6 = SDI
7 = Auto-SDI (Input 5 default)
X50%
= Output Selection
1 = ChA loopout
2 = preview
X50^
= Audio selection
40000= Analog Input A (Left)
40001= Analog Input A (Right)
40002= Digital input A (Left)
40003= Digital input A (Right)
40004= Analog Input B (Left)
40005= Analog Input B (Right)
40006= Digital input B (Left)
40007= Digital input B (Right)
60000= Output (Left, for audio mute
control only)
60001= Output (Right, for audio mute
control only)
X50&
= Audio level in 0.1 dB steps
(-180 to 240 = -18.0 to +24.0 dB)
X51)
= Overscan
0 = 0 % (default: HDMI inputs)
1 = 2.5 %
2 = 5.0 % (default: component input)
X51!
= HDCP status
0 = no sink/source detected
1 = HDCP detected,
2 = sink/source detected but no HDCP
X51@
= HDCP notification
0 = on (green HDCP notification-screen)
1 = off (mute output to black)
X51$
= Input name, up to 16 characters
(default: "Input X" where "X" is the input
number)
X53)
= User/Encoder/Layout Preset number
(1 to 16)
X53!
= Preset name (up to 16 characters)
X53@
= Input preset number (1 to 128)
162SMP351 • Remote Communication and Control
