Extron electronics SMP 351 - Page 180

Command ASCII Command
(host to unit)
Response
(unit to host)
Description
Input adjustments (Input 3 only)
Pixel Phase
Set pixel phase
E
3*
X60#
PHAS
}
Phas 3*
X60#]
Set input 3 to pixel phase
X60#
Increment pixel
phase value
E
3+PHAS
}
Phas 3*
X60#]
Increment pixel phase of input 3
Decrement pixel
phase value
E
3-PHAS
}
Phas 3*
X60#]
Decrement pixel phase of input 3
View pixel phase
value
E
3 PHAS
} X60#]
View pixel phase
X60#
of input 3
Total Pixels
Set total pixels
value
E
3*
X60%
TPIX
}
Tpix 3*
X60%]
Set total pixels (per line) for input 3
to
X60%
.
Increment total
pixels value
E
3+TPIX
}
Tpix 3*
X60%]
Increment the total pixels
X60%
for
input
3 by one pixel.
Decrement total
pixels value
E
3-TPIX
}
Tpix 3*
X60%]
Decrement the total pixels
X60%
for
input 3 by one pixel.
View total pixels
value
E
3 TPIX
} X60%]
View total pixels for input 3.
Horizontal Start
Set horizontal start
E
3*
X60$
HSRT
}
Hsrt 3*
X60$]
Set the horizontal start value for input
3 to
X60$
.
Increment
horizontal start
E
3+HSRT
}
Hsrt 3*
X60$]
Increment the horizontal start value
X60$
for input 3 by one pixel.
Decrement
horizontal start
E
3-HSRT
}
Hsrt 3*
X60$]
Decrement the horizontal start value
X60$
for input 3 by one pixel.
View horizontal
start
E
3 HSRT
} X60$]
View the horizontal start value
X60$
of input 3.
Vertical Start
Set vertical start
E
3*
X60$
VSRT
}
Vsrt 3*
X60$]
Set the vertical start value of input 3
to
X60$
.
Increment vertical
start
E
3+VSRT
}
Vsrt 3*
X60$]
Increment the vertical start value
X60$
for input 3 by one pixel.
Decrement vertical
start value
E
3-VSRT
}
Vsrt 3*
X60$]
Decrement the vertical start value
X60$
for input 3 by one pixel.
View vertical start
E
3 VSRT
} X60$]
View the vertical start value
X60$
of
input 3.
Command and Response Tables (continued)
NOTES: X60# = Pixel phase 0 to 63 (default: 32)
X60$ = Horizontal and
vertical start 0 to 255 (default: 128)
X60% = Total pixels Up to +512 of the default value for the detected range
174SMP351 • Remote Communication and Control
