Command and Response Tables (continued)
NOTES:
X(
= Assigned or unassigned 0=disabled or unassigned
1=enabled or assigned
X50!
= Input number 1 to 5
X50@
= Output channel 1=A
2=B
X53)
= User/Encoder/Layout Preset Number 1 to 16
X53!
= Preset Name Up to 16 characters
X53@
= Input preset number 1 to 128
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional
Description
User Presets
Recall user preset
1*
X50@
*
X53)
.
1Rpr
X50@
*
X53)]
Set channel
X50@
to preset
number
X53)
.
Save user preset
1*
X50@
*
X53)
,
1Spr
X50@
*
X53)]
Set user preset
name
E
1*
X53)
,
X53!
PNAM
}
Pnam1*
X53)
,
X53!]
Set preset number
X53)
to
name
X53!
.
View user preset
name
E
1*
X53)
PNAM
} X53!]
View user presets
52*
X50!
#
X(
1
X(
2
X(
3...
X(
16
]
PreU
X50! X(
1
X(
2
X(
3...
X(
16
]
Verbose mode 1
Verbose mode 2/3
Input Presets
Recall input preset
2*
X50@
*
X53@
.
2Rpr
X50@
*
X53@]
Recall input preset
X53@
per
channel
X50@
.
Save input preset
2*
X50@
*
X53@
, 2Spr
X50@
*
X53@]
Set input preset
name
E
2*
X53@
,
X53!
PNAM
}
Pnam2*
X53@
,
X53!]
Set preset number
X53@
to
name
X53!
.
View input preset
name
E
2*
X53@
PNAM
} X53!]
Delete input preset
E
X2*
X53@
PRST
}
PrstX2*
X53@]
View input presets
51#
PreI
X(
1
X(
2
X(
3...
X(
128
] Verbose mode 2/3.
Encoder Presets
Recall encoder
preset
4*1*
X53)
. 4Rpr01*
X53)]
Recall preset number
X53)
.
Save encoder
preset
4* 1*
X53)
, 4Spr 01*
X53)]
Set encoder preset
name
E
4*
X53)
,
X53!
PNAM
}
Pnam4*
X53)
,
X53!]
Set encoder preset number
X53)
to name
X53!
.
View encoder
preset name
E
4*
X53)
PNAM
}
X53!]
Reset encoder
preset to default
E
X4*
X53)
PRST
}
PrstX4*
X53)]
Layout Presets
Save layout preset
7 *
X53)
,
7Spr
X53)]
Save layout preset to
X53)
.
Recall layout
preset
7*
X53)
.
7Rpr
X53)]
Recall layout preset
X53)
including input selections.
Recall layout
preset
8*
X53)
. 8Rpr
X53)]
Recall layout preset
X53)
without input selections.
Set layout preset
name
E
7*
X53)
*
X53!
PNAM
}
Pnam7*
X53)
,
X53!]
Set
X53)
to
X53!
.
View layout preset
name
E
7*
X53)
PNAM
} X53!]
Reset layout
preset to defaults
E
X7 *
X53)
PRST
}
PrstX7*
X53)]
Reset
X53)
to defaults
