Default encoder presets
The first nine encoder presets are predefined.
Preset 3 is the default value for the Archive Encoder.
Preset 9 is the default value for the Confidence Encoder.
Preset
#
Preset
Name
Resolution Video
Bit Rate
(kbps)
Frame
Rate
(fps)
Audio
Bit Rate
(kbps)
Bit Rate
Control
GOP
Length
H.264
Profile
H.264
Level
1 1080p High 1920x1080 8000 30 320 VBR 30 High 4.1
2 1080p Low 1920x1080 6000 15 128 CVBR 30 Main 3.1
*3 720p High 1280x720 5000 30 192 VBR 30 High 3.1
4 720p Low 1280x720 3000 15 128 CVBR 30 Main 3.1
5 480p High 848x480 2500 30 128 VBR 30 High 3.1
6 480p Low 848x480 1500 15 80 CVBR 30 Main 3.1
7 VGA High 1280x1024 3500 30 128 VBR 30 High 4.1
8 VGA Low 1024x768 2500 15 128 VBR 30 High 3.1
9 Confidence 512x288 350 15 * VBR 15 Base 3.0
10 User Defined
11 User Defined
12 User Defined
13 User Defined
14 User Defined
15 User Defined
16 User Defined
NOTES:
• * Audio settings are determined by the encoding for the primary recording or stream. Audio for
confidence monitoring is not re-encoded. Therefore, by default, the recording uses encoder preset 3,
and the audio bit rate is 192 kbps.
• Default record mode is video and audio.
• The predefined encoder presets can be modified by the user. If necessary, a factory reset returns all
changes to the above table values.
• Recalling default encoder preset 9 to the archive encoder subsittues the default confidence resolution
512x288 with the minimum available resolution for the archive encoder: 848x480.
User presets
User presets save current settings or recall previously saved
configurations for the selected input. User presets can be saved on
one input rate and recalled on a different input rate. There are 16 user
presets per input.
User presets save the following parameters (per input):
• Color • Presetname
• Tint • Aspect ratio
• Contrast • Brightness
Menu
Next
1H[W
1H[W
1H[W
1H[W
PRESETS
Rotate either to
select a preset to recall.
Rotate either to select
a preset # to save
current settings to.
Rotate = to select an
input.
Rotate ] to select a preset.
Rotate = to select an
input.
Rotate ] to select a preset.
ARCHIVE ENCODER
RECALL <N/A>
ARCHIVE ENCODER
SAVE <N/A>
IN<1> USER RECAL
<N/A>
IN<1> USER SAVE
<N/A>
SMP351 • Front Panel Operation 25
