See the table below for information stored in each preset type:
Setting Input Presets User Presets Auto Memory
Horizontal and Vertical Start Yes –––– Yes
Active Pixels (H Active) Yes –––– Yes
Active Lines (V Active) Yes –––– Yes
Total Pixels Yes –––– Yes
Pixel Phase Yes –––– Yes
Horizontal and Vertical Size Yes Yes Yes
Horizontal and Vertical Position Yes Yes Yes
Aspect Ratio Yes Yes ––––
Brightness and Contrast Yes Yes Yes
Color and Tint Yes Yes Yes
Input Type Yes –––– ––––
Audio Input Gain and
Attenuation
Yes –––– ––––
Preset Name Yes Yes ––––
Presets Available 128 global 16 per input
channel
32 per input
channel
Recall Location Any input
supporting the
input type saved in
the preset
Current input Automatically
recalled based on
incoming signal
SMP351 • Web-Based User Interface 86
