UMG70XV3-4EN 12.01.2009 107
12 Advanced Measuring Functions
When the Measurement is Interrupted
The behavior of the totalizers after an interruption of the measurement or after a RESET
of the flowmeter will be set in SPECIAL FUNCTION\SYSTEM SETTINGS\MEASUR-
ING\QUANTITY RECALL.
Selection of the Totalizers for Storing
It is possible to store only the totalizer value currently displayed or one value for each
flow direction. Select in SPECIAL FUNCTION\SYSTEM SETTINGS\STORING the menu
item QUANTITY STORAGE.
12.2.2 Overflow of the Totalizers
The overflow behavior of the totalizers can be set:
Without overflow:
• The totalizer value increases to the internal limit of 10
38
.
• The values will be displayed as exponential numbers (±1.00000E10), if necessary. The
totalizer can only be reset manually to zero.
With overflow:
• The totalizer will be reset to zero automatically as soon as ±9999999999 is reached.
Select SPECIAL FUNCTION\SYSTEM SETTINGS\MEASURING\QUANT. WRAPPING.
The totalizers can be reset manually to zero independently of the selected list item.
If ON is selected, the totalizer values will be stored and
used for the next measurement.
If OFF is selected, the totalizers will be reset to zero.
If ONE is selected, only the totalizer value currently dis-
played will be stored.
If BOTH is selected, the totalizer values for both flow direc-
tions will be stored.
Press ENTER.
Select ON to work with overflow. Select OFF to work with-
out overflow.
Quantity Storage
one >BOTH<
