B Menu Structure
input of the length of an extension cable
When a calculation channel is selected (Y, Z)
Calculation channels are only available if the flowmeter has more than one
measuring channel.
display of the current calculation function
selection of the calculation function
Program Branch MEASURING
main menu: selection of the program branch
MEASURING
activation of the channels
This display will not be indicated, if the flow-
meter has only one measuring channel.
input of the measuring point number
This display is indicated only if OUTPUT OP-
TIONS/STORE MEAS.DATA and/or SERIAL
OUTPUT has been activated.
activating/deactivating the flow profile correc-
tion
This display is indicated only if UNCORR. has
been selected in SPECIAL FUNCTION\SYS-
TEM SETTINGS\MEASURING\FLOW VE-
LOCITY.
cold start
resistant
Additional cable
65.0 m
Calculation:
Y= A - B
>CH1< funct ch2 
A - B
par >MEA< opt sf
Measuring
CHANN: >A< B Y Z
MEASUR  - .
Meas. Point No.:
1 ()
A: PROFILE CORR.
>NO< yes
