FT-111, User Manual Rev. 2.0.0, June 2022 Page 120 of 137
01010
10
01011
11
CN (Label number)
01100
01110
12
14
Not used
01111
15
Set Point-1
10000
16
Set Point-2
10001
17
Set Point-3
10010
18
Set Point-4
10011
19
Set Point-5
10100
11110
20
30
Not used
11111
31
Expanded Commands List (Refer to Table 12-4)
B0
CMD Flag
Toggles
The command is applied successfully
ALL Status (always 32 bit integer)
1
st
.
Refer to 2
nd
Dword of PLC Output to FT-111 Input.
Bit Number
1st Dword (input) Description
B31
Place of decimal point
0
None
1
No decimal point
B30
0
None
1
Decimal point is X.X
B29
0
None
1
Decimal point is X.XX
B28
0
None
1
Decimal point is X.XXX
B27
0
None
1
Decimal point is X.XXXX
Not in use
B13
High resolution status
0
Passive
1
Active
B12
Centre of zero
0
Weight is out of zero range
1
Weight is in zero range
B11
Key lock status
0
Passive
1
Active
Not in use
B6
Unit indication
0
First Unit (power on unit)
1
Second Unit
B5
Power On Zero
0
Not power on zeroed
1
Zeroed with power on zero
B4
Not in use
B3
Indication
0
Gross mode
1
Net mode
B2
Motion Detection
0
Stable
1
Unstable
Not in use
Table 12-2 - ALL Status table
