FT-111, User Manual Rev. 2.0.0, June 2022 Page 36 of 137
S GRO Free set point of gross weight
The digital output is activated with comparing the set point and weight at gross weight indication as seen
below.
SPC1 Control mode-1
The digital outputs are activated as seen below, if set points are set up to Control mode-1 and their values are
entered consequently from set point 1 to the set point N how much needed.
Digital outputs which are not used at this mode can be programmed freely to any other function. For
example, if SP5 is not needed to control, it can be programmed to the zero range to produce empty signal.
SPC2 Control mode-2
The digital outputs are activated as seen below, if set points are set up to Control mode-2 and their values are
entered consequently from set point 1 to the set point N how much needed.
Digital outputs which are not used at this mode can be programmed freely to any other function. For
example, if SP5 is not needed to control, it can be programmed to the zero range to produce empty signal.
