FT-111, User Manual Rev. 2.0.0, June 2022 Page 55 of 137
[
19-
ETHERCAT
]
ETHERCAT CONFIGURATION (Appears if the option is installed)
Press key or key again to enter this menu.
Press key to go to the beginning of the sub-block or press
key to go to the next main block.
[
191
FORMAT
:
INTG
]
Data format of the EtherCAT
Page 111
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point implied.
32 bit float, decimal point implied.
[
19-
CC-LINK
]
CC-LINK CONFIGURATION (Appears if the option is installed)
Press key or key again to enter this menu.
Press key to go to the beginning of the sub-block or press
key to go to the next main block.
[
191
FORMAT
:
INTG
]
Data format of the CC-Link
Page 114
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point implied.
32 bit float, decimal point implied.
[
192
ADDRESS
:
001
]
Node address
[
193
BAUD
:
156K
]
Baud rate
156K
625K
2.5M
5M
10M
:
:
:
:
:
156 kbps
625 kbps
2.5 Mbps
5 Mbps
10 Mbps
[
19-
POWERLINK
]
POWERLINK CONFIGURATION (Appears if the option is installed)
Press key or key again to enter this menu.
Press key to go to the beginning of the sub-block or press
key to go to the next main-block.
[
191
FORMAT
:
INTG
]
Data format of the Powerlink
Page 116
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point implied.
32 bit float, decimal point implied.
[
192
ADDRESS
:
001
]
Node address
