FOR-A HVS-3800HS User Manual

187
16-5. Editor Control (Option Software)
Display FUNCTION menu by pressing FUNC button, and then open the EDITOR menu.
Parameters Description Setting Range
TYPE Protocol type GVG-100 (default), BVS-3000
DELAY (*1)
Adds delay to offset timing
mismatch
OFF: No delay
ON: Delay added (default)
ENABLE (*2) Editor control ON/OFF
ON: Editor control disabled
OFF: Editor control enabled (default)
SELECT (*3)
Selects which
bus used by the
editor.
BVS3K
ME ME operation when ENABLE is set to ON.
PVW PVW operation when ENABLE is set to ON.
ALL ME and PVW operation when ENABLE is set to ON.
ME
ON
M/E operation regardless of the ENABLE setting.
ME and PVW operation when ENABLE is set to ON
PVW
ON
PVW operation regardless of the ENABLE setting.
ME and PVW operation when ENABLE is set to ON.
WIPE
Selects how
pattern
selections are
made by editor
NORMAL 100 wipe patterns are available at editor (default)
LIST
Uses 25 patterns (as no. 75-99) saved at MU pattern
lists. (When GVG-100 is set)
BAUD Sets baud rate 9600, 19200, 38400 (default)
PARITY Sets parity NONE, ODD (default), EVEN
XPT
CTRL(*4)
Sets XPT
control type
INPUT
Crosspoint switching command from the editor by specifying
the input connector number (default).
BUTTON
Crosspoint switching command from the editor by specifying
the bus button number.
PATT
SELECT
Sets pattern
selection
ON/OFF
ON Accepts pattern commands from the editor (default).
OFF Not accept pattern commands from the editor.
KEYER CTRL
Sets keyer
commands
ON/OFF
ON Accepts keyer commands from the editor(default).
OFF
Not accept keyer commands from the editor
(Receiving "ALL STOP" command does not set keyers OFF.)
(*1) If DELAY set to OFF, command delay for DVE processing can be removed. Once command delay is
removed, MIX or WIPE transition can start at IN point of the effect, but note that in this case DVE transition
operation and commands normally issued from OU will be delayed by one frame, for example, a
background image can be accidentally seen for a moment at the beginning of the switching.
(*2) The switcher will be editor controlled only when the ENABLE is set ON.
(*3) When PVW, PVW ON or ALL is set for SELECT, AUX10 will be editor controlled as an Edit Preview bus.
(*4) Refer to the tables below to specify the number for the signals when the XPT CTRL is set to INPUT or to
BUTTON.
BUTTON（HVS-16OUA） BUTTON（HVS-12ROUA） INPUT
Number Button Name Number Button Name Number Button Name
1-16 1 o 16 1-12 1 to 12 0 BLACK
17 MATT 13-24 SHIFT+1 to 12 1-28 IN01-IN28
18-33 SHIFT+1 to 16 25 M/E 35 COLOR BAR
34 SHIFT+MATT 36 WHITE
BUTTON（HVS-24OUA） 29-36 STILL1-6
1-24 1 to 24 37-38 MATT1-2
25 MATT 39 M/E
26-49 SHIFT+1 to 24
50 SHIFT+MATT
IMPORTANT
The EDITOR ON/OFF function can be also assigned to a USER button. Once the
function is assigned to a USER button, turning the USER button on/off allows users to
set EDITOR to ON/OFF and pressing the USER button twice will open the EDITOR
menu. See section 15-2. "USER Buttons" for the assignment.
