84
6-7-2. WIPE MODIFY Menu
When modifying a WIPE pattern, changes can be made to the WIPE position or movement
angle, multi-wipe, aspect ratio, edges, borders, and mosaic and other subeffects. The
parameters that can be set are shown in the table below.
Menu
button
Menu Description (Setting)
POS
POSITION
(*1)
X, Y X-axis and Y-axis wipe center axis offset
ANGLE Movement angle offset
MULTI X, Y
Number of divisions in the X-direction and
Y-direction during multi-wipe
ASPECT Pattern aspect ratio
SOFT
Boundary edge
softness setting
0: Hard edge
ANGLE SPIN Angle auto-move setting
EFFECT
TYPE Effect types
MOSAIC, MONO,
PAINT, NEGA, SEPIA
LEVEL
Effect level set by
TYPE
1 to 16 (MOSAIC,
PAINT only)
INVERT Effect invert ON/OFF set by TYPE
EDGE EDGE
TYPE Edge type
OFF: No edge
SQU: Square edge
SAW: Saw tooth edge
RIP: Wavy edge
MODE Edge effect direction
AMP (*2) Edge height
FREQ (*2) Edge pattern frequency
POS Edge base position
POS MOVE Position auto-move setting
BORDER BORDER
SELECT Border ON/OFF
SIGNAL Signal used for border
WIDTH Border width
COLOR
SAT
LUM
HUE
Colors used for border
* Some parameter setting cannot be changed depending on the WIPE pattern. The value cannot be
changed when NONE is displayed.
(*1) The WIPE POS in the joystick section is a shortcut to the POSITION parameter. Clicking the button
enables changes to be made using the joystick without opening the menu. Double-clicking moves to the
menu fader effects.
(*2) Flicker can occur in the effects for certain AMP and FREQ settings. Therefore, be careful when making
the settings.
