FOR-A HVS-3800HS User Manual

9
1-6. STATUS Menu
STATUS menu (STATUS button)
Submenu / Parameter Description Refer to
1. MU ALARM
Displays alarm information for the MU power supply and
cooling fan.
2. OU ALARM Displays alarm information for the OU power supply.
3. AUX XPT STATUS Displays signal assignment information for AUX output.
4. KEY XPT STATUS Displays signal assignment information for keys.
5. VERSION Displays software information.
6. OPTION STATUS Displays option information.
6. OPTION STATUS Displays option information.
SELECT
Selects submenus (Press F1 or the DOWN button to select
submenus).
STATUS (1/6) menu
Submenu Parameter Description Refer to
POWER
PS1 Displays alarm information for the MU standard power supply.
2-2-1
FAN1 Displays fan alarm information for MU standard power supply.
PS2 Displays alarm information for the MU redundant power supply.
FAN2 Displays fan alarm information for MU redundant power supply.
BTRY Displays memory backup battery information.
FAN
FRONT
LEFT
Displays fan alarm information for the front right (the observer’s
left) cooling fan.
RIGHT
Displays fan alarm information for the front left (the observer’s
right) cooling fan.
SIDE
UPPER Displays fan alarm information for side upper cooling fan.
BOTTOM Displays fan alarm information for side bottom cooling fan.
REAR
UPPER Displays fan alarm information for the upper rear.
1-4
Displays alarm information for the four lower rear fans (1 - 4
from left to right).
STATUS (2/6) menu
Submenu Parameter Description Refer to
POWER
PS1 Displays alarm information for the OU standard power supply.
PS2 Displays alarm information for the OU redundant power supply.
FAN (HVS-12ROUA) Displays alarm information for the OU cooling fan.
CARD
BUS_CD Displays the BUS_CARD information.
TRANS_CD Displays the TRANS_CARD information.
STATUS (3/6) menu
Submenu Parameter Description Refer to
AUX 1-16 Displays signal assignments of the AUX 1-16.
SELECT INPUT/BUS NAME Displays which display type is selected, INPUT or BUT NAME.
STATUS (4/6) menu
Submenu Parameter Description Refer to
M/E1
M/E2
KEY1
KEY2
KEY3
INS Displays signal assignments of the KEY INSERT.
SRC Displays signal assignments of the KEY SOURCE.
STATUS (5/6) menu
Submenu Parameter Description Refer to
MU SOFT Displays the MU main software version.
16-7-1
-SUB CPU Displays the MU sub software version.
OU SOFT Displays the OU software version.
-SUB CPU (HVS-16/24OUA) Displays the OU sub software version.
DVE
1 Displays the DVE software version.
16-8
2 Displays the optional DVE software version.
