2-2-4. MU Rear Panel Cards
This section shows examples of HVS-3800HS/S internal configurations and basic
connections.
IMPORTANT
Before touching the cards and other components inside the HVS-3800HS/S, be sure
to turn off the Power switch of the MU and disconnect the front panel and rear unit to
prevent electric shock. If the MU case needs to be opened to make settings or
adjustments, be sure that the work is performed by an experienced technician, or
contact your FOR-A supplier.
HVS-3800HS/S Front Panel Side
HVS-3800HS/S Rear Panel Side
HVS-3800 Front Panel Side
No. Slot Standard module Optional module
1 1 - HVS-38UC, HVS-38DC
2 2 - HVS-38AUMV, HVS-38SS, HVS-38SSAM
3 3 M/E CARD, DVE CARD, SDI CARD
A
4
MU PS1 (Power supply unit 1)
B MU PS2 (Power supply unit 2)
Power supply unit 2Power supply unit 1
Screw Screw
1
2
AC100-240V 5 0/60Hz I N
1
92
3
45 67
10 14
11 12
13 15 16
8
6
5
1
23
4789
10
11 12
13 1514 16
IN PUT
OUT PUT
CP UGL
12 LAN 1GPI IN
CPU
ED ITOR GPI/T ALLY OUT
RS-422
(10/100 BASE-T)
ARCNET
45
GL
3
RS-422
ALARM TRI SYNC IN BB IN
REF OUT
12
OUT PU T INPU T CPUCP U
