180
16-2-3. Assigning the VTR Operation to the USER Button
Press the FUNC button in the menu section to display the FUNCTION top page.
Set SELECT to USER BUTTON. Press the control F1 or the DOWN button to display the
FUNCTION-FREE ASSIGN menu.
Select the user button to use for assigning the VTR Control Function under the BUTTON
item. The light of the corresponding USER button turns on.
Set TYPE to FUNC.
Turn F3 to select the VTR control operation that you want to assign for the selected
USER button. Press ENTER in the keypad to confirm the setting.
VTR Control Using User Buttons
VTR operations are assigned using the Free Assign function.
Step 1. VTR function set to ON
Press the upper right button to set the VTR function to ON. When pressed, the button turns
orange. (If you want to set the VTR function OFF, press the button again to light off.)
Step 2. Operating the VTR
Press the VTR control buttons (REW, PLAY, FF, PAUSE, STOP, or REC) to operate the VTR.
The button does not turn on or off during this operation.
16-2-4. VTR Control Using the Menu (VTR Protocol)
Press the FUNC button in the menu section to display the FUNCTION top page.
Set SELECT to VTR. Press F1 or the DOWN button to display the FUNCTION - VTR
menu.
Turn F1 to select the VTR to be controlled.
Use the control F1 to F6 in the bottom page to control the selected VTR. To perform the
recording operation, turn F3 to change to ENABLE and then press F3 to start recording.
NOTE
STILL5, STILL6, S5(S6) or (S5)S6 can be selected for the SELECT item if the HVS-
38SSAM6/12 optional card is installed to your unit. This allows you to playback moving
video. See the HVS-38SSAM6/12 operation manual for details.
MU SETUP VTR
SELECT
VTR1
REW
STOP
JG-REV
REC
DISABLE
PLAY JG-FWD
TIME CODE
FF PAUSE
H M S F
00 : 00 : 00 : 00
