16-1-4. Setup Example for AUX OUT Tally
The AUX OUT tally, which indicates the status of an AUX output, can be also used in the
switcher. It would be useful in a case where AUX outputs are used for video source
monitoring. This section shows how to set up an AUX OUT tally. As an example, let us take a
case when Red tally is sent (red tally on) when the video source monitored through AUX1 is
sent to on-air (displayed on the program out).
Conditions:
AUX OUT: AUX1
On-air bus: M/E2PGM
Tally color: RED
Output pin: Pin1 on TALLY Unit1
Setting:

Open the [FUNCTION - GPI/TALLY - TALLY COLOR] menu.
 Turn F1 to select M/E2PGM at SELECT. Press F1 to open the submenu.
 Turn F1 to select RED at SELECT. Turn F2 to set ENABLE to ON to enable the selected
tally color.
 Press the UP button to return to the [FUNCTION - GPI/TALLY] menu. Then open the
[FUNCTION-GPI/ TALLY - TALLY 1] menu.
 Make the setting for the TALLY1 menu as shown below.
FUNCTION GPI/TALLY TALLY COLOR(2/2)
RED
GREEN
COLOR1
COLOR2
COLOR3
SELECT
1
COLOR4
COLOR5
COLOR6
COLOR7
COLOR8
COLOR9
COLOR10
ENABLE
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
FUNCTION GPI/TALLY TALLY COLOR(1/2)
1. M/E1 PGM
2. M/E1 PST
3. M/E2 PGM
4. M/E2 PST
5. AUX 1
SELECT
3
6. AUX 2
7. AUX 3
8. AUX 4
9. AUX 5
10. AUX 6
11. AUX 7
12. AUX 8
13. AUX 9
14. AUX 10
FUNCTION GPI/TALLY TALLY1
1RED
2 RED
3 RED
4 RED
5 RED
P NO.
1
TYPE
TALLY
ENABLE
ON
TALLY - AUX01 TLY_FLW
TALLY - IN01
TALLY - IN02
TALLY - IN03
TALLY - IN04
COLOR
RED
INPUT
AUX01
