FOR-A HVS-3800HS User Manual

145
14. Color Correction (Option)
HVS-38CC/SCC Color Corrector options provide Color Correction and Proc Amp capabilities for
HVS-3800 series switchers. These options support all HD/SD SDI signal formats handled by
HVS-3800 switchers.
14-1. Color Correction Overview
 Supports all inputs and output of HD SDI (multi-format) and SD SDI (multi bit-rate) digital
signal formats supported by HVS-3800HS/S
 Provides up to 10 color correction channels : 2 for each M/E bus and 2 for keyers of each M/E
and 2 for AUX buses.
 Assignable to PGM, PST, KEY1, KEY2, KEY3 buses of each M/E and AUX1-10 buses.
 Proc Amp capability includes Video Level, Chroma Level Chroma Phase and Black Level
control.
 Separate or group adjustment for RGB White/Black/Gamma levels.
 Three Color Correction modes available: BAL(balanced), DIF(differential) and SEPIA.
 Two Clip modes available: YPbPr(YCbCr) and RGB(GBR)
 Color Correction, Clip Adjustment and Proc Amp settings can be stored in the event memory
and sequence memory.
 The assignment function of Color Correction channels and the channel status display can be
allocated to USER buttons.
14-2. Color Corrector Specifications
One option of HVS-38CC or HVS-38SCC (software option) can be installed into HVS-3800HS/S.
This means up to 10 channels of Color Correction channels can be used in HVS-3800 series
switchers.
Color
Corrector
HVS-38CC/SCC
Module ME1 BG ME1KEY ME2 BG ME2KEY AUX
Number of
channels
2 2 2 2 2
Assignable
bus
M/E1PGM
M/E1PST
M/E1KEY1-3
M/E2PGM
M/E2PST
M/E2 KEY1-3 AUX1-10
Assignment
type
Output bus, Input signal, Bus button
Proc Amp Luminance level, Chroma level, Chroma phase, Black level
Color
Correction
RGB White/Black/Gamma
Clip
Adjustment
YPbPr, RGB
