FOR-A HVS-3800HS - KEY Menu

16
1-13. KEY Menu
KEY1 - SOURCE/INSERT (1/6) menu
KEY2 - SOURCE/INSERT (1/6) menu
KEY3 - SOURCE/INSERT (1/2) menu
Submenu Parameter Default Setting Range Refer to
KEY TYPE BUS BUS, LUM, CHR 5-6-2
INSERT
TYPE BUS BUS, MATT 5-6-6
SIGNAL TYPE=BUS IN01 Signal name
5-6-3
5-6-4
SOURCE
SIGNAL IN01 Signal name
INVERT OFF OFF, ON 5-8-1
FAM OFF OFF, ON
5-7
KEY SIGNAL
GAIN 1.0 0.0 to 27.0
CLIP 50 0.0 to 100.0
TRANSP 0.0 0.0 to 100.0
TRANSITION
RATE* 30 0 to 999 6-9-1
LIMIT OFF OFF, ON
6-9-2
LEVEL 100.0 0.0 to 100.0
* TRANSITION RATE and TRANSITION LEVEL can be also set at AUTO TRANS RATE - KEY1 (KEY2) and
FADER LIMIT - KEY1 (KEY2) parameters in the TRANS menu respectively.
KEY1 - MATT/MASK (2/6) menu
KEY2 - MATT/MASK (2/6) menu
KEY3 - MATT/MASK (2/2) menu
Submenu Parameter Default Setting Range Refer to
MATT COLOR
SAT
HD 66.3
0.0 to 100.0
5-6-6
SD 66.7
LUM
HD 5.4
0.0 to 100.0
SD 8.5
HUE
HD 3.5
0.0 to 359.5
SD 7.5
MASK
TYPE OFF
OFF, BOX_A, BOX_O,
KEY3_A, KEY3_O
5-8-2
INVERT OFF OFF, ON
TOP
1080
0
0 to 540
720 0 to 360
NTSC
4: 3, SQUEEZ 0 to 242
LETTER 0 to 180
PAL 0 to 287
LEFT
1080
0
0 to 1920
720 0 to 640
SD 0 to 720
RIGHT
1080
0
0 to 1920
720 0 to 640
SD 0 to 720
BOTTOM
1080
0
0 to 540
720 0 to 360
NTSC
4: 3, SQUEEZ 0 to 242
LETTER 0 to 180
PAL 0 to 287
