FOR-A HVS-3800HS User Manual

156
15. Additional Features
In addition to signal switching features explained thus far, the SETUP menu of the HVS-3800series
switchers also allows users to make several settings and checks that are more of a convenience
nature.
15-1. System Setup
Operation settings, such as the brightness of the menu screen, buzzer sound mode, fader lever
and joystick response, and screensaver, can be made in the OU SETUP - MODE menu. To
access the OU SETUP menu page, use the F1 control in the OU SETUP top menu (see the
figures below) to select the respective submenu, and then press the F1 control or the DOWN
button.
15-1-1. OU SETUP Menu
 Joystick response, screen saver and display brightness, and fader lever response
Parameter Description Default Setting Range
JOYSTICK Sets the joystick response level. ACCEL
LOW, NOR, HIGH,
ACCEL
TYPE Selects screen saver type. TIME TIME, BALL, OFF
MIN Defines wait time (in minutes). 5 1 to 60
BRIGHTNESS
Adjusts brightness level of the
screen.
10 1-15
Turn F1 to select, and then press F1or DOWN button to move to OU MODE menu.
OU SETUP Ver.1.00.1
1.BUS CTRL
2.USER BUTTON
3.MODE
4.FADER
5.NETWORK
SELECT
3
OU SETUP MODE(1/2)
BUTTON
CTRL
LIVE
TYPE
TYPE1
RATE
TYPE
FRM
BUZZER
VOLUME
16
JOY
STICK
NORMAL
TONE
NORMAL
SELECT
TIME
BRIGHT
NESS
10
MIN
5
SCREEN SAVER SHIFT
SELECT
NORMAL
OU
INIT
OFF
ON AIR
TYPE
M/E2
OU SETUP MODE(2/2)
KEYTRS
MENU
SHOW
RENC
TYPE
NORMAL
TRANS
DISP
HOLD
RENC
SPEED
HIGH
KEYER
FAMNAM
DISBLE
