154
14-8. Assigning Functions to User Buttons
The color corrector channels can be allocated to video signals by using user buttons, if the color
corrector type is set to INPUT or BUTTON. If the color corrector type is set to BUS, user button
assignments cannot be used. To assign a signal to the color corrector with a user button, a
signal should be specified in the AUX/KEY bus.
In addition, the usage status of color correction channels can be dynamically obtained by using
user buttons.
14-8-1. Allocating Channels to User Buttons
Selecting a Color Correction Channel
To allocate a color correction channel to a desired user button, proceed as follows.
Press the OU SETUP button in the menu section to open the OU SETUP top menu.
Turn F1 to select USER BUTTON. Press F1 or the DOWN button to open the USER
BUTTON menu.
In the USER BUTTON menu, turn F1 to select a user button. The selected user button
will be flashing green.
Turn F2 to select FUNC under the TYPE item. Press F2 to confirm the selection.
Turn F3 to select a color correction channel to be allocated to the user button. (See the
table below.) Press F3 to confirm the selection.
FUNC setting
ME1 BG-CC1 SEL（INPUT/BTN）
ME1 BG-CC2 SEL（INPUT/BTN）
ME1KEY-CC1 SEL（INPUT/BTN）
ME1KEY-CC2 SEL（INPUT/BTN）
ME2 BG-CC1 SEL（INPUT/BTN）
ME2 BG-CC2 SEL（INPUT/BTN）
ME2KEY-CC1 SEL（INPUT/BTN）
ME2KEY-CC2 SEL（INPUT/BTN）
AUX-CC1 SEL(INPUT/BTN)
AUX-CC2 SEL(INPUT/BTN)
Once the color correction channel is allocated to a user button, the Color Correction menu
will open by pressing the user button twice quickly.
Selecting a Video Signal
Press and light up the user button where the color correction channel is allocated. All of
the buttons in the AUX/KEY bus light off.
Select a signal to be assigned to the color correction channel in the AUX/KEY. If the color
corrector type is set to INPUT, the channel is assigned to the input signal. If the color
corrector type is set to BUTTON, the channel is assigned to the bus button. This color
corrector assignment is applied to both M/E and AUX/KEY buses.
