PULS SYNERGIC (MIG/MAG pulse synergic welding)
-
SYNERGIC (MIG/MAG standard synergic welding)
-
MANUAL (MIG/MAG standard manual welding)
-
LSC/PMC (LSC = Low Spatter Control, PMC = Pulse Multi Control)
Depending on which function package is enabled
-
STICK/TIG (MMA welding/TIG welding)
-
CMT / SP (CMT welding / special programs)
(10) USB port
For updating the software using a USB Ethernet adapter
(11) Mode selection
The corresponding LED lights up when a mode is selected.
The following modes can be selected by pressing the button:
-
2T (2-step mode)
-
4T (4-step mode)
-
S4T (Special 4-step mode)
-
S2T (Special 2-step mode)
-
MODE (Special modes depending on the function package)
(12) Gas-test button
For setting the required gas flow rate on the gas pressure regulator.
After pressing this button, gas flows for 30 seconds. Press the button
again to stop the gas flow prematurely.
(13) Wire threading button
To thread the wire electrode into the torch hosepack with no accompany-
ing flow of gas or current
(14) Left adjusting dial with turn/press function
-
For setting the sheet thickness, welding current, wire speed, F1, pen-
etration stabilizer and arc length stabilizer parameters
-
For displaying help texts
Turn the adjusting dial to:
select parameters, change values, display long help texts
Press the adjusting dial to:
confirm a menu selection, apply values, call up help texts for parameters
(15) Favourites button
Individual parameters or parent folders can be assigned to it
(16) Filler metal info button
For showing the currently set filler metal
(17) Filler metal selection button
For selecting the filler metal
49
EN
