Pulse/dynamic correction
The function varies according to the welding process being used. A de-
scription of the various functions can be found in the Welding chapter un-
der the corresponding welding process.
Special function
Any parameter can be assigned to this
The function can be selected if a parameter has been saved.
* Synergic parameter
When a synergic parameter is changed, the synergic function automatic-
ally changes all other synergic parameters to match.
(6) Indicators
SFI indicator
Lights up when SFI (Spatter Free Ignition) is active
SynchroPulse indicator
Lights up when SynchroPulse is active
VRD indicator
Lights up when the voltage reduction device (VRD) is active
(7) EasyJob buttons
For saving, retrieving and deleting EasyJobs
The LED on the corresponding button lights up when an EasyJob is selec-
ted.
(8) Right adjusting dial with turn/press function
For setting the arc length correction, welding voltage, pulse/dynamic cor-
rection and F2 parameters
Turn the adjusting dial to:
change values, select parameters (in the Setup menu and when selecting
the filler metal)
Press the adjusting dial to:
confirm a menu selection, apply values
(9) Welding process selection
The corresponding LED lights up when a welding process is selected.
The following welding processes can be selected by pressing the button:
48
