Arc length stabilizer
The "Penetration stabilizer" and "Arc length stabilizer" process control
parameters can only be selected when the LSC/PMC welding process is
used.
The currently adjustable parameter is marked with an arrow.
* Synergic parameter When a synergic parameter is changed, the synergic
function automatically changes all other synergic parameters to match.
(3) Display
For displaying values
(4) Hold/Intermediate arc indicator
Hold indicator
The indicator lights up at the end of each welding operation and the actu-
al values for the welding current, welding voltage and wire speed, etc. are
automatically shown on the display.
Intermediate arc indicator
The indicator lights up when a spatter-prone intermediate arc occurs
between the dip transfer arc and the spray arc.
(5) Right parameter selection
The corresponding indicator lights up when a parameter is selected.
The following parameters can be selected by pressing the button:
Arc length correction
For correcting the arc length
Welding voltage *
In V
Before the start of welding, the machine automatically displays a standard
value based on the programmed parameters. The actual value is displayed
during welding.
