132 4 Paper
3. Gently slide the tray back in as far as it will go.
Important
• When inserting the tray, push it gently. Forcibly pushing the
tray in may cause machine malfunction.
Changing the Paper Size for Tray 6
1. Pull out Tray 6 until it stops.
2. Remove any paper loaded in the tray.
3. Open the end guide (1) and unscrew the screw
(2). And then remove the guide from the tray.
4. Insert the small protrusions at the bottom of
the guide into the holes corresponding to the
paper size (1). Insert the protrusion on the
tray into a hole corresponding to the paper
size on the top of the guide, and tighten up
the screw (2).
To Next Page
