U41117-J-Z125-7-76 357
XTCC Elements of the XTCC window
The status line is contained at the bottom edge of the Groups window:
Autoscan green = released
yellow = active
flashing red= stopped / temporarily discontinued
white = locked (Simu mode)
S Autoscan operating mode(S = Automatic setting, M = Manual setting)
5s Autoscan interval
If the group display is minimized, you can reopen it simply by clicking the appropriate tab.
When you select a group, its color changes to blue. If you then click your left mouse button,
the group is transferred to the configuration display and its number appears in the
“Group m of n” field in the tab in the top right-hand corner.
The group currently displayed is colored beige.
The host adapters and SCSI controllers are always displayed together with each group.
If you rest the mouse pointer on one of the small color boxes, a small window appears
containing the name of that object. In the case of /390 emulations, the emulation name is
displayed together with its mnemonic name.
Click the tab to open the group display
for the entire ISP.
