Elements of the XTCC window XTCC
Color codes in the group display
The object colors used in the group display are very similar to those in the configuration
display:
SYS HA Ct Emu/
Manager/
Server
Target/
V-Drive
RAID
Turquoise OK ACTIVE OK Running
and
attached
Read/write,
read only,
busy
OK
Green Running
and not
attached
Pink ACTIVATING
CHAN_DISAB
CONFIGURED
FAILED
INACTIVE
INITIAL
STOPPED
Hanging
11)
Stopped Online,
offline
Error
Ye l l o w
12)
Unknown Unknown Unknown Unknown Warning
White Removed
10)
T: Removed
13)
Red File
system
1)
VLM halt
PLM error
VJUK: Offline
Emu
ERR_CFG
8)
MIM/SIM
9)
Black File
system
2)
SNMP
3)
CLEAN
4)
BUSY
5)
INFO
6)
MIM/SIM
7)
Brown Trace on
