Figure 176: Routing the FBU cable
▶
Route the FBU cable as shown in the figure.
In configuration with internal RAID controller
, the FBU cable is stored
under the internal RAID riser module.
Expansion cards and backup units
RX2530 M6
Upgrade and Maintenance Manual
255
