Note when tightening the screws of the CPU heat sink:
▶
As shown in the figure below, tighten the screws while checking the screw
tip until it is visible through the screw hole.
▶
When you reach the above position, hold the screw driver with two fingers
and tighten the screw firmly.
Figure 198: Installing the EVAC CPU heat sink
Processor (CPU)
288 Upgrade and Maintenance Manual RX2530 M6
