Install the EVAC CPU heat sink in the same way.
▶
Fasten the two additional screws (see circles) with torque 0.6
Nm.
Upgrading the main memory
▶
Select an adequate memory configuration, see "Basic information" on
page 264.
▶
Install memory modules, see "Installing a memory module" on page 271.
Installing four additional fan modules
In case of 1 CPU configurations with dual rotor fans, the bays 5, 6, 7
and 8 are occupied with fan cage foams.
Figure 199: Removing fan cage foams
▶
Remove the fan cage foams from the bays 5, 6, 7 and 8.
▶
Install four fan modules in bays 5, 6, 7 and 8, see "Installing the new fan
module" on page
192
.
Processor (CPU)
RX2530 M6 Upgrade and Maintenance Manual 289
