CAUTION
CPUs are extremely sensitive to electrostatic discharge and therefore
must always be handled with care.
▶
After a CPU has been removed from its protective sleeve or from its
socket, place it upside down on a nonconducting, antistatic surface.
▶
Never push a CPU over a surface.
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
"Suspending BitLocker functionality" on page 75
.
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
▶
"Removing the air duct" on page 73.
Removing the heat sink
Figure 200: Removing the heat sink (A)
Processor (CPU)
RX2530 M6 Upgrade and Maintenance Manual 291
