Removing the CPU
Figure 211: Removing the CPU
▶
Open the lever of the CPU frame to lift up the CPU (1).
▶
Remove the CPU from the CPU frame (2).
▶
Clean residual thermal paste from the CPU surface using a lint-free cloth
and store the CPU in a save place.
CAUTION
CPUs are extremely sensitive to electrostatic discharge and therefore
must always be handled with care.
▶
After a CPU has been removed from its protective sleeve or from
its socket, place it upside down on a nonconducting, antistatic
surface.
▶
Never push a CPU over a surface.
▶
Disengage the four edges of the CPU frame and remove the CPU frame (3).
Liquid cooling (LC)
RX2530 M6 Upgrade and Maintenance Manual 303
