Installing the CPU
CAUTION
When replacing a system board
▶
Use a magnifying glass (recommended) to inspect the socket
spring contacts for damages from different angles. Do not use the
spare system board if any irregularities are visible. Possible
damages:
–
Contact spring is bent backwards upon itself
–
Contact spring tip position is shifted or out of alignment
▶
Never try to fix bent contact springs. Doing so may result in loss of
electrical performance and reliability.
Figure 212: CPU in packaging
▶
Remain the CPU in the packaging.
Liquid cooling (LC)
304 Upgrade and Maintenance Manual RX2530 M6
