Fujitsu PRIMERGY RX2530 M6

Figure 216: Installing the LC heat sink (A)
▶
Push the four latches inward (see arrows).
▶
Carefully place the LC heat sink onto the CPU socket.
Take care of air flow direction.
Figure 217: Installing the LC heat sink (B)
Liquid cooling (LC)
308 Upgrade and Maintenance Manual RX2530 M6
