Removing the ODD
Figure 230: Disconnecting the cable from the ODD
▶
Disconnect the ODD cable from the ODD (1).
▶
Press the ODD latch in direction of the arrow until it disengages (2).
Figure 231: Removing the ODD
▶
Pull the ODD out of the bay.
Accessible drives
320 Upgrade and Maintenance Manual RX2530 M6
