Fujitsu PRIMERGY RX2530 M6

Removing the COP
The COP and the front panel cable are combined in one spare part.
Figure 234: Removing the front panel cable
▶
Pull up the locking bar (1).
▶
Disconnect the front panel cable (2).
▶
Remove the front panel cable from the cable clips (see circles).
Figure 235: Removing the COP (A)
Front panel
RX2530 M6 Upgrade and Maintenance Manual 327
