If applicable, move the M.2 SSD latch to a fitting position:
▶
Turn the M.2 SSD latch for 90 degrees (1).
▶
Remove the M.2 SSD latch (2).
▶
Install the M.2 SSD latch in the right position depending on the length of
the M.2 SSD (3).
▶
Turn the M.2 SSD latch for 90 degrees (4).
System board and components
366 Upgrade and Maintenance Manual RX2530 M6
