"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page
49.
▶
Disconnect all external cables.
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 113.
▶
If applicable, remove the OCP modules, see "Removing the OCP module"
on page 215.
▶
"Getting access to the component" on page 52.
▶
For a system with air cooling, proceed as follows:
▶
"Removing the air duct" on page 73.
▶
Remove all memory modules, see "Removing a memory module" on
page 274.
Before removing the memory modules, take a note on the
installation slot number for each memory module. Ensure that you
reinstall the memory modules in the slot they were located before
the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
Remove all dummy memory modules, see "Removing a memory dummy
module" on page 276.
System board and components
388 Upgrade and Maintenance Manual RX2530 M6
