For a system with liquid cooling, proceed as follows:
▶
Remove the LC kit, see "Removing the LC kit" on page 300.
▶
Remove all memory modules, see "Removing a memory module" on
page 274.
Before removing the memory modules, take a note on the
installation slot number for each memory module. Ensure that you
reinstall the memory modules in the slot they were located before
the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
Remove all fans, see "Removing the defective fan module" on page
192.
▶
Remove all riser modules, see "Expansion cards and riser cards" on
page 217
.
▶
Remove the iRMC microSD card, see "Removing the iRMC microSD card"
on page 362.
▶
If applicable, remove all M.2 SSDs, see "Removing the M.2 SSD" on
page 370.
▶
If applicable, remove the Dual microSD 64GB Enterprise, see "Removing
the Dual microSD 64GB Enterprise" on page 377.
▶
If applicable, remove the VROC module, see "Removing the VROC
module" on page 384.
Removing the defective system board
▶
Disconnect all cables from the system board.
System board and components
RX2530 M6 Upgrade and Maintenance Manual 389
