Fujitsu PRIMERGY RX2530 M6

Pos. Print Description
3 PWR 3
4 PWR 2
5 FAN 8_SYS Power connector for system fan 8
6 LC2 Connector for LC pump for CPU 2
7 FAN 7_SYS Power connector for system fan 7
8 SLIMLINE 4 (CPU 2)
9 FAN 6_SYS Power connector for system fan 6
10 SLIMLINE 3 (CPU 2)
11 FAN 5_SYS Power connector for system fan 5
12 SMB 1
13 FAN 4_SYS Power connector for system fan 4
14 LC1 Connector for LC pump for CPU 1
15 FAN 3_SYS Power connector for system fan 3
16 SLIMLINE 2 (CPU 1)
17 FAN 2_SYS Power connector for system fan 2
18 SLIMLINE 1 (CPU 1)
19 FAN 1_SYS Power connector for system fan 1
20 PWR 1
21 SATA ODD/8 SATA connector for ODD
22 PWR ODD Power connector for ODD
23 SATA 4-7 SATA HDD connector
24 ROC Connector for Dual microSD 64GB Enterprise
cable
25 VROC
26 Rear Serial Connector for optional serial interface
27 SATA 0-3 SATA HDD connector
28 SATA 9
Appendix A
RX2530 M6 Upgrade and Maintenance Manual 407
