Fujitsu PRIMERGY RX2530 M6

Pos. Print Description
29 HDD LED Connector for HDD LED cable (e.g. PRAID
EP5xxi)
30 USB 3 Connector for Dual microSD 64GB Enterprise
31 M.2 SSD2 M.2 slot 2
32 M.2 SSD1 M.2 slot 1
33 micro SD iRMC microSD card
34 Front VGA Connector for optional front VGA
35 SMB 3
36 TPM Connector for optional TPM
37 PWR 5
38 Front Panel Front panel connector
39 SLIMLINE 6 (CPU 2)
40 PSU2 Power connector for PSU 2
41 SLIMLINE 5 (CPU 2)
42 PSU1 Power connector for PSU 1
Appendix A
408 Upgrade and Maintenance Manual RX2530 M6
