Installing the new fan module
Figure 77: Installing the fan module
â–¶
Press the latches (1).
â–¶
Install the fan module in the fan bay and press down the fan module until it
locks (2).
Concluding steps
â–¶
"Reassembling" on page
53
.
When a system fan module fails, the remaining fans will start
operating at full speed. After the defective fan module has been
replaced, all fans will continue to run at full speed for a couple of
minutes, before resetting to a lower speed.
Ensure that all system fans reset to a normal operating speed.
â–¶
If applicable, "Installing the front cover with lock" on page 61.
â–¶
"Performing a fan test" on page 1
14.
Fans
170 Upgrade and Maintenance Manual RX4770 M6
