â–¶
Remove the two slot covers.
CAUTION
â–¶
Keep the slot cover for future use.
â–¶
If the expansion card is removed and not replaced with a new
one, the slot cover must be reinstalled due to cooling, to comply
with applicable EMC regulations and to protect against fire.
Figure 119: Installing a GPU card in a riser module
â–¶
Install the GPU in the riser module.
Expansion cards and backup units
216 Upgrade and Maintenance Manual RX4770 M6
