Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 45
.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
Installing the FBU in the FBU holder
Figure 132: Installing the FBU in the holder
Expansion cards and backup units
228 Upgrade and Maintenance Manual RX4770 M6
