Pos. Print Description
1 CN1 Connector for Slimline-SAS to PCIe
2 CN2 Connector for Slimline-SAS to PCIe
3 LC3 Connector for LC pump for CPU 3
4 LC4 Connector for LC pump for CPU 4
5 CN3 Connector for Slimline-SAS to PCIe
6 CN4 Connector for Slimline-SAS to PCIe
Appendix A
RX4770 M6 Upgrade and Maintenance Manual 401
