GE Responder 2000 Service Manual

SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
™
2000 Page 105
STAR
®
BIPHASIC Defibrillation Waveform
The waveform generated by the Responder 2000 is a BIPHASIC TRUNCATED EXPONENTIAL waveform compliant with
ANSI/AAMI DF80.
STAR
®
Biphasic Waveform – 270J into Pads or paddles
Table A - 270J Waveform into Different Resistive Loads (Typical Values)
Patient’s
Impedance
(Ohms)
Phase 1
Delivered
Start Volts
Phase 1
Delivered
End Volts
Phase 1
Duration
(ms)
Phase 2
Delivered
Start Volts
Phase 2
Delivered
End Volts
Phase 2
Duration
(ms)
Total Energy
Delivered
(J)
25 1692V 990V 3.25 ms 990V 342V 3.2ms 281J
50 1860V 1234V 4.50 ms 1234V 684V 3.2ms 270J
75 1923V 1338V 5.75ms 1338V 887V 3.2ms 254J
100 1957V 1394V 7.00 ms 1394V 1015V 3.2ms 241J
125 1977V 1429V 8.25ms 1429V 1103V 3.2ms 231J
150 1991V 1453V 9.50 ms 1453V 1166V 3.2ms 223J
175 2002V 1469V 10.75ms 1469V 1214V 3.2ms 217J
180 2003V 1472V 11.00ms 1472V 1222V 3.2ms 216J
200 2009V 1520V 11.00ms 1520V 1283V 3.2ms 202J
STAR Biphasic Waveform – 50J into internal spoon
Table B – 50J Waveform into Different Resistive Loads (Typical Values)
Patient’s
Impedance
(Ohms)
Phase 1
Delivered
Start Volts
Phase 1
Delivered
End Volts
Phase 1
Duration
(ms)
Phase 2
Delivered
Start Volts
Phase 2
Delivered
End Volts
Phase 2
Duration
(ms)
Total Energy
Delivered
(J)
10 573V 217V 3.00ms 217V 27V 3.2ms 47J
20 697V 386V 3.00ms 386V 108V 3.2ms 51J
25 728V 426V 3.25 ms 426V 147V 3.2ms 52J
50 800V 531V 4.50 ms 531V 294V 3.2ms 50J
75 828V 576V 5.75ms 576V 382V 3.2ms 47J
100 842V 600V 7.00 ms 600V 437V 3.2ms 45J
