GE Responder 2000 Service Manual

SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
™
2000 Page 115
Connector: GE 43252483
Pin Number Name Description
PC15 RET_PC Return for Buttons and ID bits
PC16 ID_PDL/SPNS Pull Down Input – ID Bit –
Paddles/Spoons
APEX SHOCK_P Patient Apex
STERNUM SHOCK_M Patient Sternum
Paddle Connector ID Codes
Cable P/N Description PC14 PC16
22338301 Pacer or Defib Pads Short to PC15
22334601 Flat Pads Short to PC15
21730801 Internal Spoons 4.7K to PC15 Short to PC15
30344625 Responder Paddles Short to PC15
ECG Connector – GE ECG Connector – Five lead ECG
Connector: GE 401760-1
Pin
Number
Pin
Name
Description
1 RA Input – Right Arm
2 NC No Connection
3 NC No Connection
4 LA Input – Left Arm
5 RL Input – Right Leg
6 V Input – V
7 NC No Connection
