SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
2000 Page 134
SpO
2
PATIENT INTERFACE
Samtec FTSH-105-01-L-D-RA
Pin
Number
Name Description
1 DET+ Input – Detector Pos
2 DIGICAL_GND Ground – Calibration Data
3 DIGICAL_DAT Input – Calibration Data
4 DET- Input – Detector Neg
5 SHLD_INNER Inner Shield
6 N/C No Connection
7 LED- Output – Led Neg
8 N/C No Connection
9 LED+ Output – Led Pos
10 SHLD_OUTER Outer Shield
POWER SUPPLY MODULE
Provides DC power for the instrument via the Power Control PCBA.
TB1 – POWER INPUT
Heyco 0916 – Wire connected - Mounts on back of instrument
Pin
Number
Name Description
1 L
2 G
3 N
AC Input
90-264VAC 47-63Hz
POWER OUTPUT
Wire Connected – Plugs into Power Control PCBA
Pin
Number
Name Description
1 GND NOMINALLY 13.5V
