Section 5: Performance Verification and Safety Testing
2025653-048 Revision B Responder
™
2000 Page 62
Defibrillator Tests
Warning! Shock Hazard.
Before delivering any shock, ensure all personnel and equipment are clear of the test area.
Energy Timeout Test
1. Ensure the Responder 2000 has a charged battery (at least 25%) installed and is connected to AC power
2. Seat each paddle in its side holder. Ensure paddles are securely seated.
3. Press the Manual button on the Responder 2000.
4. Select an Energy Level of 100J.
5. Press the Charge button on the front panel.
6. The message Stand Clear is displayed.
7. Do not press the Shock button. After 30 Seconds the message Charge Time Out should be displayed.
Defibrillator Test Chart
For each of the defibrillator tests below (Paddles, Pads, and Spoons), perform the test at the energy level indicated in the
procedure. Then perform each test at the energy levels indicated in the chart below.
Note: Use only a calibrated Impulse 4000 (or equivalent) for pads and spoons. Energy values may vary slightly depending
on the simulator used.
Selected
Energy
Energy Delivered into 50 Ohm
(Tolerance +/- 15 % or +/-3 Joule)
Test
2 0-5 Paddles, Pads, and Spoons
3 0-6 Paddles, Pads, and Spoons
5 2-8 Paddles, Pads, and Spoons
7 4-10 Paddles, Pads, and Spoons
10 7-13 Paddles, Pads, and Spoons
15 12-18 Paddles, Pads, and Spoons
20 17-23 Paddles, Pads, and Spoons
30 25.5-34.5 Paddles, Pads, and Spoons
50 42.5-57.5 Paddles, Pads, and Spoons
70 59.5-80.5 Paddles and Pads only
100 85-115 Paddles and Pads only
150 127.5-172.5 Paddles and Pads only
200 170-230 Paddles and Pads only
270 229.5-310.5 Paddles and Pads only
To Next Page
