GE Responder 2000 Service Manual

Section 5: Performance Verification and Safety Testing
2025653-048 Revision B Responder
™
2000 Page 72
Leakage Current Test
Required Equipment
• Metron QA-90 Safety Analyzer (or equivalent)
Equipment Setup
Note: This setup assumes the use of a Metron QA-90 Safety Analyzer. If an equivalent safety analyzer is used, refer to
the Operator’s manual for detailed instructions.
1. Configure the Safety analyzer for following parameters.
Note: The following parameters may be saved for future use.
Leads Name Limit
Earth Leakage Current (OS) 1000 µA
Earth Leakage Current (NC) 500 µA
Earth Leakage Current (OSRM) 1000 µA
Earth Leakage Current (NCRM) 500 µA
Enclosure Leakage Current (OS) 500 µA
Enclosure Leakage Current (NC) 100 µA
Enclosure Leakage Current (OE) 5000 µA
Enclosure Leakage Current (OSRM) 500 µA
Enclosure Leakage Current (NCRM) 100 µA
Enclosure Leakage Current (OERM) 500 µA
1-2 Patient Leakage Current AC (OS) 50 µA
1-2 Patient Leakage Current AC (NC) 10 µA
1-2 Patient Leakage Current AC (OE) 50 µA
1-2 Patient Leakage Current AC (OSRM) 50 µA
1-2 Patient Leakage Current AC (NCRM) 10 µA
1-2 Patient Leakage Current AC (OERM) 50 µA
3-7 Patient Leakage Current AC (OS) 50 µA
3-7 Patient Leakage Current AC (NC) 10 µA
3-7 Patient Leakage Current AC (OE) 50 µA
3-7 Patient Leakage Current AC (OSRM) 50 µA
3-7 Patient Leakage Current AC NCRM 10 µA
3-7 Patient Leakage Current AC OERM 50 µA
