SECTION 8: Specifications and Safety
2025653-048 Revision B Responder
™
2000 Page 135
2 GND
3 GND
4 +12V
5 +12V
POWER OUTPUT IS FLOATING WITH
RESPECT TO:
EARTH GROUND
POWER INPUTS
BATTERY
Provides DC power for the instrument via the Power Control PCBA while the instrument is not plugged into an AC power
source.
J325 – Smart Battery Connector – Data and Power
Suyin 250132FB010G200ZU
Pin
Number
Name Description
1, 2, 3, 4 GND Battery Ground
5 BAT_TEMP Output – 10K to Ground
6 SMBUS_DATA Bi-directional – SMBus Data
7 SMBUS_CLK Bi-directional – SMBus Serial Clock
8, 9, 10 +12V_BAT Battery Positive
